HH-428 Computerized Cut, Strip and Twist Machine for 2 Wires
Product Features
※ This machine features computerized control, easy button operation, stable working performance. It is designed for processing the double wires by automatic cutting, stripping and twisting;
※ The length of wire head, wire end and total can be set as required within the range;
※ The speed of wire feeding, wire cutting and stripping could be separately set to reach the best effect of stripping;
※ It has the function of setting total quantity, batch quantity, time delay, and intermediate stripping, etc.;
※ Motor driver has high precision and long service life, and the system can store 99 kinds of different wire data.
Operating Video
HH-428 https://youtube.com/shorts/oulPcg8sgi4 strip and twist
Details About HH-428 Computerized Cut, Strip and Twist Machine for 2 Wires
Technical Parameters
| Machine Model | HH-428 Computerized Splitting, Cutting and Stripping Machine for Flat/ribbon Cable |
| Display Language | English |
| Max. Capacity | Around 4000～10000 pieces/h |
| Wire Range | 0.1mm²～2.5mm² |
| Cutting Precision | ﹤± (0.1+0.005*L), L= Cutting Length |
| Stripping Length | 1.0～30mm（Customization is accepted） |
| Cutter Material | Tungsten steel and high speed steel |
| Feeding Speed | 1.5m/s |
| Drive Mode | 4 wheels driven |
| Power | AC 220V, 50/Hz, 300W |
| Dimension | 420mm*320mm*400mm |
| Weight | About 35Kg |
