HH-430 Computerized Cut and Strip Machine for 16mm² Cable
Product Features
※ This machine features computerized control, easy button operation, stable working performance. It is designed for processing the middle size wire by automatic cutting and stripping;
※ The length of wire head, wire end and total can be set as required within the range;
※ The speed of wire feeding, wire cutting and stripping could be separately set to reach the best effect of stripping;
※ It has the function of setting total quantity, batch quantity, time delay, and intermediate stripping, etc.;
※ Motor driver has high precision and long service life, and the system can store 99 kinds of different wire data.
Details About HH-430 Computerized Cut and Strip Machine for 16mm² Cable
Technical Parameters
| Machine Model | HH-430 Computerized Cutting and Stripping Machine for Cable under 16 mm² |
| Display Language | English |
| Max. Capacity | Around 1500～3000 pieces/h |
| Wire Range | 0.1mm²～16mm² |
| Cutting Precision | ﹤± (0.1+0.005*L), L= Cutting Length |
| Stripping Length | 1.0～30mm（Customization is accepted） |
| Cutter Material | Tungsten steel and high speed steel |
| Feeding Speed | 0.8m/s |
| Drive Mode | 4 wheels driven |
| Power | AC 220V, 50/Hz, 450W |
| Dimension | 420mm*345mm*300mm |
| Weight | About 33Kg |
