HH-432 Computerized Cut and Strip Machine for Flat Sheath Cable
Product Features
This machine features computerized control, easy button operation, stable working performance. Itis designed for processing the flat sheathed cable by stripping the sheath and inner cores;
The length of wire head, wire end and total can be set as required within the range;
The speed of wire feeding, wire cutting and stripping could be separately set to reach the best effect of stripping;
It has the function of setting total quantity, batch quantity, time delay, and intermediate stripping, etc.;
Motor driver has high precision and long service life, and the system can store 99 kinds of different wire data.
Operating Videos:
HH-432C https://youtu.be/kDFC69-8KVo outer socket and inner cores
HH-432 https://youtu.be/LCCtEtEpXhE sheath cable
Details About HH-432 Computerized Cut and Strip Machine for Flat Sheath Cable
Technical Parameters
| Machine Model | HH-432 Computerized Cutting and Stripping Machine for Flat Sheathed Cable |
| Display Language | English |
| Max. Capacity | Around 1000～3000 pieces/h |
| Inner Cores Range | 0.1mm²～2.5mm² |
| Cutting Precision | ﹤± (0.1+0.005*L), L= Cutting Length |
| Stripping Length | Sheath（wire head 1.0～200mm; wire tail 1.0～150mm） Inner cores（wire head/tail 1.0～100mm） |
| Cutter Material | Tungsten steel and high speed steel |
| Feeding Speed | 0.7m/s |
| Drive Mode | 4 wheels driven |
| Power & Air Supply | AC 220V, 50/Hz, 300W, 0.4～0.5Mpa |
| Dimension | 420mm*345mm*300mm |
| Weight | About 31Kg |
